| Name: | Vacuum Atmosphere Furnace | Operation Temperature: | 1600℃ |
|---|---|---|---|
| Chamber Size: | 150x150x150mm | Heating Element: | MoSi2 Rod |
| Vacuum Level: | -0.1MPa | Temperature Accuracy: | ±1℃ |
| Temperature Measure: | By B Type Thermocouple | Insulation Material: | High Purity Alumina Ceramic Fiber Plate |
| Furnace Structure: | Double Shells With Fan Cooling | Heating Rate: | ≤15℃/min |
| High Light: | nitrogen atmosphere furnace,controlled atmosphere furnace |
||
) Muffle furnace adopted high quality alumina polycrystalline fiber, which used alumina polycrystalline fiber) with good insulation and durability properties, high tensile strength and no miscellaneous ball; Chamber surface coated with imported 1700 degree high temperature resistant heat insulation coating, it can improve the reflectivity and the heat efficiency of furnace, and prolong the service life of furnace. So this furnace much more energy saving than the furnace use common fiber materials.
2) Muffle furnace with high quality silicon molybdenum rod as heating elements, high heating efficiency,greatly improving the service life.
3) Muffle furnace with assembling structure, through strict computation, durable to use, does not collapse; equipped with breathing holes, can reduce shrinkage of furnace chamber and prolong the service life.
4) Side open type furnace door, open the door power will be cut off automatically.
5) Reserved 485 convert interface, can be connected with PC through software. It has remote control, real time tracking, history recorder, and output report function.
Features of SUPER vacuum electric box furnace
1700C Atmosphere sintering muffle furnace Atmosphere sintering muffle furnace have below outstanding feature:
1: Better leak tightness.
2: Better heating preservation,
3: Atmosphere can be controlled.
4: Safety and explosion provention.
5: Precise temperature control.
6: Max Vacuum can up to -0.1Mpa
The supply of technical information together with electric box furnace:
1. Furnace operation manual
2. The maintenance solution of the common problems .
3. Electrical control schematic drawing
Technical support and after sale service :
1. Prompt technical consulation and support will be offered .
2. Provide consumable parts with favorable price
3. A whole year warranty and lifetime maintenance .
Technical parameter of 100x100x100mm vacuum atmosphere furnace :
| Product Name | Vacuum atmosphere chamber furnace |
| Model | SP-1700BA-1L |
| Max Tempearture | 1700℃(<3 Hours) |
| Working Tempearature | 1600℃(Continuous) |
| Max Vacuum | -0.1MPa |
| Inner chamber Size | 150*150*150mm or customizatable |
| Furnace structure | Double Shells with fan cooling |
| Temperature Controller | 50 Segment programmable and PID auto control |
| Temperature Accuracy | +/-1 °c |
| Heating Elements | MoSi2 heating element |
| Heating Rate | 20°c/Minutes(Suggestion<15°c) |
| Thermocouple | k type |
| Rated Power | 3.5KW |
| Rater Voltage | AC 380V (50/60hz) |
Stanard models of SUPER company 1700C atmosphere electric box furnace :
| Chamber Size | 1200C | 1400C | 1700C |
| 100x100x100mm(4”x4”x4”) | SP-1200BA-1L | SP-1400BA-1L | SP-1700BA-1L |
| 150x150x150mm(6”x6”x6”) | SP-1200BA-3.4L | SP-1400BA-3.4L | SP-1700BA-3.4L |
| 150x150x200mm(6”x6”x8”) | SP-1200BA-4.5L | SP-1400BA-4.5L | SP-1700BA-4.5L |
| 200x200x200mm(8”x8”x8”) | SP-1200BA-8L | SP-1400BA-8L | SP-1700BA-8L |
| 200x200x300mm(8”x8”x12”) | SP-1200BA-12L | SP-1400BA-12L | SP-1700BA-12L |
| 250x250x300mm(10”x10”x12”) | SP-1200BA-19L | SP-1400BA-19L | SP-1700BA-19L |
| 300x300x400mm(12”x12”x16”) | SP-1200BA-36L | SP-1400BA-36L | SP-1700BA-36L |
| 350x350x400mm(14”x14”x16”) | SP-1200BA-49L | SP-1400BA-49L | SP-1700BA-49L |
| 400x400x400mm(16”x16”x16”) | SP-1200BA-64L | SP-1400BA-64L | SP-1700BA-64L |
| 500x500x500mm(20”x20”x20”) | SP-1200BA-125L | SP-1400BA-125L | SP-1700BA-125L |
| 600x600x600mm(24”x24”x24”) | SP-1200BA-216L | SP-1400BA-216L | SP-1700BA-216L |
Special requirement for this furnace is also available .
