|Product:||Induction Melting Furnace||Rated Capacity:||350kg|
|Rated Temperature:||1650C||Rated Power:||300KW|
|Melting Rate:||380kg/h||Power Consumption:||0.68kwh/kg|
|Water Consumption:||8t/h||Usage:||Melting Furnace|
induction heating furnace,
metal casting furnace
Performances and features of induction melting furnace :
1. Using a zero-voltage scanning soft-start mode, in any case may at any time to start or stop, will not have impact on power supply.
2. Fast smelting with low production cost; low-pollution and environment-friendly ;
3. A direct effect from the cold furnace melting. Dissolved material will be fully dumped clean. Molten material easy to replace.
4. Power adjustment flexibility. Be able to continuously smooth adjustment. Temperature uniformity can be easily controlled. Oxidation burning less. Metal components evenly.
5. Furnace shell using cast aluminum or steel structure, small footprint; furnace flip dump convenience, according to the need to use electric, manual, hydraulic tilting furnace and other means.
6. Designed to automatically adjust angle of inverter circuit that can automatically adjust the load impedance match, without adjustment of capacitance compensation and always run the equipment in good working condition; power supply system diagnostic error function, easy maintenance.
Induction melting furnace eight protection :
1. over voltage protection
2. over current protection
3. low voltage protection
4. lack phase protection
5. lack voltage protection
6. water pressure protection
7. water temperature protection
8. water flow protection.
This induction melting furnace is applicable for melting, heating and holding of steel, copper, iron, aluminum, zinc, tin, nickel and other ferrous of nonferrous metal.can also be used for forging, sintering and tube-bending forming in casting and melting industrials.
Thecnical parameter of 350kg induction melting furnace:
|Product name and model||GW-0.35 Medium Frequency Induction Furnace|
|Medium Frequency power||300KW|
|Induction coil voltage||1000V|
|Tilting furnace device||Electric reducer|
|Furnace shell structure||Casting aluminum shell|
Packing & Shipping
Small induction melting furnace will be packed by standard plywood case for exporting ;
Suppose your order is of big volume or 1pc furnace with large capacity, the products will be delivered by 20GP or 40GP container. Top open container is optional as well.
