Payment & Shipping Terms:
|Rated Capacity:||2ton Brass||MF Rated Power:||1000kw|
|Power Input Voltage:||660V||Melting Frequency:||500HZ|
|Melting Rate:||60mins/batch At Hot Condition||Power Consumption:||440kwh/t|
|Water Circulation:||30tons/h||Induction Coil Votlage:||2000V|
|Rated Temperature:||1200℃||Full Set:||Furnace Body , Capacitor Bank , Power Cabinet ,tilting System|
electric induction furnace,
metal casting furnace
1. Applications of casting smelting furnace : used for melting stainless steel, alloy steel, carbon steel.
2. Features of casting smelting furnace : fast speed of melting, saving energy, less burnt loss, pure molten liquid.
3. The aluminum frame of casting smelting furnace is adopted to small capacity smelting furnace with reasonable structure and small capacity, convenient installation and simple maintenance, low maintenance cost.
4. The induction coils of fast melting furnace are double paralleled winded with prolonged coil to make sure the half capacity of furnace molten liquid can be heated by full load power output which will improve overall efficiency. Cooling system is equipped along with the induction coil prolong the lining life.
5. The inner wall of induction coil of large capacity electric furnace is cast with imported high temperature resistant insulation material to prevent of furnace lining leakage.
Structure Features of electric induction furnace:
1. Solid steel structure and durable;
2. Good magnetic isolation, safe and reliable;
3. Solid frequency conversion power supply, easy operation; Adjustable power rate, easy operation and maintenance
4. Easy to start up with load or free of load
Furnace block, l Hydraulic mechanism, Operation table, Low-voltage power supply system;Electro thermal capacitor cabinet, Water temperature and pressure annunciator;Water cooling cables, Furnace leakage alarm
Technical parameter of electric induction furnace :
Packing & Shipping
Small induction metal melting furnace will be packed by standard plywood case for exporting ;
Suppose your order is of big volume or 1pc furnace with large capacity, the products will be delivered by 20GP or 40GP container. Top open container is optional as well.
