Product Details:
Payment & Shipping Terms:
|
| Name: | Gold Silver Melting Machine | Temperature Control: | PID Temperature Control |
|---|---|---|---|
| Volume: | 1-3kg Gold | Crucible: | High Purity Graphite Crucible |
| Rated Temperature: | 1150C | Packing Size: | 38.5x38.5x44cm |
| Shipping Weight: | 13kg | Type: | Resistance Furnace |
| High Light: | 3kg Gold Silver Melting Machine,PID Control Gold Silver Melting Machine,PID Control 3kg gold melting furnace |
||
1. Introduction of Gold Silver Melting Machine :
Gold Silver Melting Machine adopts the principle of magnetic induction eddy current heating and use electric current to generate magnetic field through coil. When a magnetic field line passes through metal material in magnetic field, it makes boiler body heat at high speed on its own, and then heat material again.
2.Advantage of Gold Silver Melting Machine :
※ Fast speed of melting, saving energy, less burnt loss, pure molten liquid.
※ Well designed for handheld pouring directly from the crucible;
※ Good quality, competitive price, perfect technical support, and perfect after-sale service.
Thanks to use of a heat-resistant and efficient insulation, the radially arranged heating element can give full effect and a homogeneous temperature distribution results in the melting crucible. The high performance and the good insulation ensure a rapid reaching of the desired melting temperature.
In addition to housing insulation, a thermally insulated grid protects against accidental contact with the heating chamber. This is an important safety feature when dealing with the melting furnaces. To match the melting crucible, we supply a melting tongs that fit into the groove around the crucible head. This allows you to work safely with the hot melt crucible.
3. Technical data of Gold Silver Melting Machine :
| Furnace capacity | 1kg | 2kg | 3kg |
| Power input( (w) | 1500 | 1600 | 1700 |
| Power supply(220v) | 50,60hz/7A | 50,60hz/7.5A | 50,60hz/8A |
| Power supply(110v) | 50,60Hz/14A | 50,60Hz/15A | 50,60Hz/16A |
| Measurement accuracy | + 0.5%FS | + 0.5%FS | + 0.5%FS |
| Working environment | 0-50°C, 30-85%RH | 0-50°C, 30-85%RH | 0-50°C, 30-85%RH |
| Net size(cm) | L31xW36xH37 | L31xW36xH37 | L31xW36xH37 |
| Packing size(cm) | L38xL38xH42 | L38xL38xH42 | L38xL38xH42 |
| Net weight(kg) | 11 | 11 | 11 |
| Packing weight(kg) | 13 | 13 | 13 |
4. packaging of small gol silver melting furnace:
* Normal Package:Carton box package for each set furnace,internally fill with foam to protect furnace .
* If over 10 sets,it will be packaged with the pallet;this way can save a lot of your purchasing cost.
* We have professional packaging and shipping insurance so your purchase will arrive safely.
5.SUPER Machinery Delivery time
* For some normal standard size furnaces and components, we have in stock; So we can send out in 2-3 days;
* Other customized sizes the delivery time is from 7 days to 15 days according to different products request.
6. SUPER Machinery Warranty :
(1) control circuit 1 year ;
(2) furnace pipe 6 months;
(3) heating elements: for pure gold and silver warranty for 3 months ;if for corrosive material ,no warranty.
